The CF-410 Series is the most efficient high flow self-priming pumps available. Low power consumptions, super hydrostatic bring extreme atomization enjoyment.
item no.:
CF-410lead time:
7-30 daysproduct orgin:
FUJIANshipping port:
FUZHOU(MAWEI)payment:
TTcolor:
BLACKCF-410 Series High flow agriculture sprayer pump
WIDELY USED - for Vehicle cleaning, ship,carpet cleaning, floor cleaning,water purification and water treatment equipment; washing, bathing, toilet, washing water, agriculture, processing equipment, the pipe pressurization system, solar industry;
Self-contained pressure relief circuit device, when the pump is turned off, automatically decompress and recirculate. The pressure in the pipe will not increase and the pipe will not burst, overloads flowing protected;
NOT SUMMERSIBLE, the water inlet must be equipped with a filtering device and cannot enter impurities; Otherwise, the pressure adjustment have been set up in a suitable value.
Specification
|
Max Flow rate |
15LPM ( 4.0gpm) |
|
Max Pressure |
40PSI (2.8bar) |
|
Motor Voltage |
12V/24VDC |
|
Control type |
Switch & By pass |
|
Housing Material |
Nylon / Polypropylene |
|
Valves / Seals Material |
EPDM/VITION |
|
Wire Connection |
2-PIN Leads |
|
Diaphragm |
Santoprene |
Features And Benefits
Typical Applications
Pump Configurations
| Model | Voltage (V) | Flow (LPM/GPM) | Pressure off (psi/bar) | AMP Draw(A) | Inner box(mm) | N.W/G.W(kg) |
| CF-410 | 12 | 15/4.0 | 40/2.8 | 6.5 | 340×120×105 | 2.20/2.50 |
| CF-411 | 24 | 15/4.0 | 40/2.8 | 4 | 340×120×105 | 2.20/2.50 |
Dimensions
Fittings for your option:
PACKAGING & DELIVERY
Packaging Details: Colour box / White box 340*120*105mm
Port: FUZHOU
Picture Example:
| PACKING DETAILS | CARTOM | |||
| Giftbox Size (CM) | N.W/G.W ( KG ) | PCS/CTN | CARTOM SIZE (CM) | G.W ( KG ) |
| 34 * 12 * 10.5 | 1.9 / 2.2 | 10 | 64*36*24.6 |
22.6 |
Lead Time:
| Quantity(Pieces) | 1 - 1000 | >1000 |
| Est. Time(days) | 15 | To be negotiated |
