The A Series and B series RO water booster pump is our continuous-duty on-demand positive displacement pump. It provides reliable performance in moderate water flow, high-pressure applications.
product orgin:
FUJIANpayment:
TT LCcolor:
BLACK12v 24v Reverse Osmosis booster Diaphragm Water Pump
This 3 chamber diaphragm pump provides up to 1.8 gallons per minute and is capable of self-priming up to 6 vertical feet, and reverse osmosis pump can run dry without damage. This 12v dc booster pump has a built-in pressure switch, which automatically starts and stops when the fixture is opened and closed. They are easy to install, service and winterize.
Specification
|
PUMP |
|
|
Type |
3 Chamber positive displacement diaphragm pump, self priming, capable of being run dry |
|
Control Type |
pressure switch controlled or by-pass controlled |
|
Max Recommended Temperature |
60° C (140° F) |
|
Priming Capabilities |
6 feet (1.8 m) suction lift |
|
Pressure off |
Shut-off Pressure60 PSI :45 PSI ±5 PSI (±0.3 bar)
Shut-off Pressure 80 PSI : 65 PSI ±5 PSI (±0.3 bar) Shut-off Pressure120 PSI :105 PSI ±5 PSI (±0.3 bar) Shut-off Pressure160 PSI :145 PSI ±5 PSI (±0.3 bar) Shut-off Pressure170 PSI :155 PSI ±5 PSI (±0.3 bar)
|
|
Inlet/Outlet Ports |
3/8"-18 FNPT |
|
Valve |
EPDM |
|
Wire Connections |
2-Pin/Leads |
|
MOTOR |
|
|
Leads |
16 AWG, 13" (33 cm) long with 2-Pin connector / Leads |
|
Duty Cycle |
Intermittent/continuous |
|
Max.Amp Draw |
10.8A |
Features and Benefits
Typical Application
Marine, RV, Agricultural Spraying, General Industrial, Filtration, Beverage Processing, Solar Water System, etc.
Standard Pump Configurations
|
Model |
Volts |
Open flow(LPM) |
Max Draw（A) |
Inch |
PSI |
Power Connection |
Inner box |
|
CFDP-3201-01 |
12 |
5.5 |
6 |
3/8"FNPT |
60 |
2-Pin/Leads |
26.6x12x10.5 |
|
CFDP-3401-01 |
24 |
5.5 |
3.1 |
3/8"FNPT |
60 |
2-Pin/Leads |
26.6x12x10.5 |
|
CFDP-3201-02 |
12 |
5.5 |
7 |
3/8"FNPT |
80 |
2-Pin/Leads |
26.6x12x10.5 |
|
CFDP-3401-02 |
24 |
5.5 |
3.7 |
3/8"FNPT |
80 |
2-Pin/Leads |
26.6x12x10.5 |
|
CFDP-3202-01 |
12 |
5.5 |
9 |
3/8"FNPT |
100 |
2-Pin/Leads |
26.6x12x10.5 |
|
CFDP-3402-01 |
24 |
5.5 |
4.6 |
3/8"FNPT |
100 |
2-Pin/Leads |
26.6x12x10.5 |
|
CFDP-3202-02 |
12 |
5.5 |
9.5 |
3/8"FNPT |
120 |
2-Pin/Leads |
26.6x12x10.5 |
|
CFDP-3402-0212 |
24 |
5.5 |
4.8 |
3/8"FNPT |
120 |
2-Pin/Leads |
26.6x12x10.5 |
|
CFDP-3203-01 |
12 |
5.5 |
10.5 |
3/8"FNPT |
160 |
2-Pin/Leads |
26.6x13x10.5 |
|
CFDP-3403-021 |
24 |
5.5 |
5.3 |
3/8"FNPT |
160 |
2-Pin/Leads |
26.6x13x10.5 |
|
Item |
Description |
Quantity |
|
A |
Pump head assembly |
1 |
|
B |
Valve assembly |
1 |
|
C |
Diaphragm assembly |
1 |
|
D |
Motor assembly |
1 |
|
1 |
Pressure switch |
1 |
|
2 |
Diaphragm of pressure switch |
1 |
|
3 |
Pump head |
1 |
|
4 |
Diaphragm |
1 |
|
5 |
Rubber feet |
1 |
|
6 |
Iron base plate |
1 |
|
7 |
Motor |
1 |
Shipping information
|
Unit pump weight(N.W/G.W) |
1.9/2.1kg 2.4/2.65 |
|
Unit size |
260*120*100mm |
|
Mater carton size |
63*29*23.5cm |
|
Mater carton quantity |
10pcs |
|
Mater carton weight |
27kgs |
Lead Time
| Quantity(Pieces) | 1 - 1000 | >1000 |
| Est. Time(days) | 15 | To be negotiated |
